CN20 RW

THE NEXT INFRASTRUCTURE SOLUTION OF CONTINEST

The CN20 RW is based on the CN20 model.

MOST IMPORTANT UPGREDES ARE
- usage of rockwool panels (RW) with an A1 (non-combustible material,European Standard EN 13501), fire resistance index EI 30, sound reduction >30dB
- placement of the fuse board at 200 cm height, in line with the Israeli electrical code
- usage of energy efficient, dimmable LED panels
- two-pole sockets with protective contact (AC 16 A 250 V 50Hz) for unrestricted use secondary safety for the end user)
SIZE
- Closed: 6060×2440×540 mm
- Open: 6060×2440×2750 mm
- Inner length: 5830 mm
- Inner width: 2310 mm
- Inner height: 2470 mm
WEIGHT
- 2250 kg
ELECTRICAL CONNECTION
- 3 x double socket (NN) type F (CEE 7/3 – two-pole sockets with protective contact AC 16 A 250 V 50Hz) for unrestricted use.
- General lighting, switchable ON/OFF with an illuminance of 200 lux (reference height of illuminance: 0,75 m above ground) energy efficiency class: A++ in accordance with “Ecodesign Directive 2009/125/EC” (Regulation 874/2012/EU Annex VI).
  Dimmable LED panels of 300×1200 mm
- Electrical switch box on a foldable panel at 2m above the floor level of the container – In case of the “IDF” version.
- Grounding.
- Durable rubber electrical cables.
- 32A 3 phase incoming and outgoing connection for further container electrical supply.
